Multi-Agent Architecture

AuroraSOC employs 16 specialized AI agents organized in a hub-and-spoke topology. This page explains the architectural decisions behind this design and how agents collaborate.

Why Multiple Specialized Agents?

A single general-purpose agent struggles with the breadth of security operations. Consider:

• A malware analyst needs deep knowledge of reverse engineering, YARA rules, and sandbox behavior
• A compliance analyst needs knowledge of NIST, ISO 27001, HIPAA, PCI-DSS frameworks
• A CPS security specialist needs understanding of industrial protocols (Modbus, DNP3, OPC UA)

No single LLM prompt can effectively cover all these domains. Specialization allows:

1. Focused system prompts — Each agent has a tailored persona with domain expertise
2. Relevant tool sets — Each agent only sees tools relevant to its domain
3. Optimized memory — Memory presets tuned per agent type
4. Independent scaling — Scale hot agents without scaling cold ones

The Hub-and-Spoke Topology

The Orchestrator

The Orchestrator is the only agent that can directly communicate with all other agents. It:

1. Receives tasks from users or the event pipeline
2. Analyzes the task to determine which specialists are needed
3. Dispatches work using HandoffTools (one per specialist agent)
4. Aggregates results from multiple specialists
5. Synthesizes a final response

The Orchestrator does NOT do the actual security analysis — it's a coordinator.

HandoffTools

Each specialist agent is exposed to the Orchestrator as a HandoffTool:

# From aurorasoc/agents/orchestrator/server.py
handoff_tools = []
for agent_type in AgentType:
    if agent_type != AgentType.ORCHESTRATOR:
        tool = HandoffTool(
            agent=agent_type.value,
            description=f"Delegate to {agent_type.value} specialist"
        )
        handoff_tools.append(tool)

This means the Orchestrator's LLM sees tools like:

• handoff_security_analyst — "Delegate to security_analyst specialist"
• handoff_threat_hunter — "Delegate to threat_hunter specialist"
• handoff_malware_analyst — "Delegate to malware_analyst specialist"
• ... (15 total)

Agent Communication: A2A Protocol

Agents communicate over HTTP using the Agent-to-Agent (A2A) protocol:

Why A2A over Direct Function Calls?

Approach	Pros	Cons
Direct function calls	Fast, simple	Tight coupling, single process, no scaling
Message queue	Decoupled, scalable	Complex, async, harder to debug
A2A Protocol	Decoupled yet synchronous, standard protocol, independently deployable	HTTP overhead (minimal)

A2A was chosen because:

• Each agent runs as an independent HTTP service (separate container)
• Agents can be deployed on different machines for scaling
• The protocol is standardized — any A2A-compatible agent can join
• Health checks and circuit breakers work naturally with HTTP

Parallel Dispatch

For complex investigations, the Orchestrator dispatches to multiple agents simultaneously:

The dispatch_parallel() function in the dispatch module sends requests concurrently using asyncio.gather(), dramatically reducing investigation time.

Agent Factory Pattern

All agents are created by the AuroraAgentFactory:

Every agent receives:

1. A specialized system prompt from prompts.py
2. ThinkTool as the first tool (forced at step 1 for reasoning)
3. Domain-specific MCP tools relevant to its role
4. TieredAgentMemory with a preset matching its memory needs

Design Decision: Central Factory

Why a single factory instead of each agent constructing itself? Because:

1. Consistency — All agents follow the same construction pattern
2. Configuration — Central place to modify agent creation
3. Testing — Easy to mock factory for unit tests
4. Inventory — Single source of truth for all agent types
